Compact yet Resilient
The XM7-20 is a compact, yet rugged 2-inch (58mm) premium level Auto-ID Mobile Liner and Linerless Label printer featuring an intuitive design and value add software support. A premium level printer, capable of speeds up to 6ips at 300dpi print resolution, it provides a drop protection of 2.1 metres and an IP54 protection rating. Through a smart battery with universal USB Type-C Power delivery charging, this mobile label printer provides a wealth of battery health information through BIXOLON’s web-based printer profile management software XPM™, guaranteeing consistent performance throughout prolonged operations, making it ideal for Logistics, Manufacturing, Retail and Healthcare printing applications.
A high connective device, the XM7-20 presents USB 2-0 and Serial interfaces as standard, with optional Bluetooth V5.0 Classic (MFi Certification) and WLAN 802.11a/b/g/n wireless technology which can be connected simultaneously. Supporting easy Bluetooth pairing via NFC allows compatibility with major operations including Android™, iOS™ and Windows™. The printer also boasts compatibility with market leading command languages such as SLCS, BPL-Z™, BPL-C™ and BXL/POS to allow for seamless integration with customers’ existing systems.
Boasting a 128 MB SRAM, 256 MB Flash memory as standard and optional 256 MB SDRAM, 512 MB Flash memory enabling the storage of fonts and graphics, alongside firmware upgrades and tools. The XM7-20 can print directly from SAP® Smart Forms and is compatible with a range of label editing applications including BIXOLON’s Label Artist™, Label Artist Mobile™ for iOS™ & Android™, alongside the industry leading Bartender® software.
Printing
- Print technology: Direct thermal
- Type: Mobile printer
- Maximum resolution: 203 x 203 DPI
- Number of printable dots: 8 dot
- Print speed: 6 ips
- Print speed: 152 mm/sec
- Character sets: 16 BPL-Z,SLCS
Paper handling
- Supported paper width: 25 - 58 mm
- Maximum printing width: 48 mm
- Maximum roll diameter: 57 mm
- Media thickness: 0.07 ± 0.19 mm
Ports & interfaces
- Connectivity technology: Wired & Wireless
- USB port: Yes
- USB connector: USB Type-C
- Serial interface: Yes
- Serial interface type: RS-232
- Bluetooth: Yes
- Bluetooth version: 5.0
Network
- Ethernet LAN: No
- Wi-Fi: Yes
- Wi-Fi standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n)
- Security algorithms: 40-bit WEP,104-bit WEP,WPA,WPA2
Features
- Page description languages: CPCL-native,ZPL II
- Internal memory: 128 MB
- Storage media: Flash
- Flash memory: 256 MB
Design
- Product colour: Black
- Built-in display: Yes
- Display: LCD
- Colour display: No
- Display resolution: 240 x 320 pixels
Power
- Power source type: Battery
- Battery technology: Lithium-Ion (Li-Ion)
- Battery voltage: 7.2 V
- Battery capacity: 2850 mAh
Operational conditions
- Operating temperature (T-T): -15 - 50 °C
- Storage temperature (T-T): -30 - 70 °C
- Operating relative humidity (H-H): 10 - 80 %
System requirements
- Windows operating systems supported: Yes
- Mac compatibility: Yes
- Mobile operating systems supported: Android,iOS
- Linux operating systems supported: Yes
Weight & dimensions
- Width: 92.9 mm
- Depth: 168.2 mm
- Height: 69.2 mm
- Weight: 600 g
Packaging content
- Drivers included: Yes
Logistics data
- Harmonized System (HS) code: 84433210
Technical details
- Sustainability certificates: ENERGY STAR
Other features
- International Protection (IP) code: IP54
