The versatility to drive cross-sector performance
The UX10 has been designed to deliver portable performance across a range of industries, including Industrial Manufacturing, Public Safety and Utility Services, in even the most demanding environments.
Ultimately secure rugged tablet
An optional hard handle makes the UX10 easy to grip and carry, allowing you to take the computing power you require to the place it is most needed.
A detachable keyboard with retractable hard handle further optimises worker productivity. For total security in authenticating users, the UX10 has an optional integrated fingerprint reader, smart card reader, magnetic stripe reader, an RFID reader, and can also offer a Windows Hello face-authentication camera.
The connected tablet
The UX10 seamlessly supports digital transformation, offering digital connectivity through BT, WiFi, and optional 4G LTE. An optional RS232 port can support legacy equipment. An optional RFID reader allows information feed-back into the management system. All these functionalities ensure the UX10 stays connected no matter whether outdoors or indoors.
The ‘always-on’ tablet
In a world where devices need to work 24/7/365 power-up continuity is essential – in portable devices that means a focus on battery configuration. The UX10 offers a range of battery configurations and options, including an optional high capacity battery and an optional bridge battery that ensures a ‘hot swap’ capability. In effect you need never power-down the UX10, making it ideal if the device is pooled between workers or required across multiple work shifts.
The usable-in-all conditions tablet
Drop resistance and temperature tolerance aside, the LumiBond® screen ensures usability in all conditions. 1000 nits of brightness make the display readable even in sunlight, whilst rain and glove touch capability guarantee visibility and productivity in even the most extreme conditions.
ATEX and IECEx Certified
Certified for hazardous locations, the UX10 fully rugged tablet offers optional ATEX and IECEx Zone 2/22 certification for use in potentially explosive atmospheres.
Display
- Display diagonal: 10.1 "
- Display resolution: 1920 x 1200 pixels
- Panel type: IPS
- Touchscreen type: Capacitive
Processor
- Processor manufacturer: Intel
- Processor family: Intel® Core™ i5
- Processor generation: 8th gen Intel® Core™ i5
- Processor model: i5-8265U
- Processor cores: 4
- Processor threads: 8
- Processor boost frequency: 3.9 GHz
- Processor frequency: 1.6 GHz
- Processor cache: 6 MB
- Processor cache type: Smart Cache
- Tjunction: 100 °C
- Configurable TDP-down frequency: 0.8 GHz
- Processor package size: 46x24 mm
- Processor operating modes: 64-bit
- Thermal Design Power (TDP): 15 W
- System bus rate: 4 GT/s
- Processor codename: Whiskey Lake
- Thermal Monitoring Technologies: Yes
- Supported instruction sets: AVX 2.0,SSE4.1,SSE4.2
- Bus type: OPI
- PCI Express configurations: 1x4,2x2
- Processor lithography: 14 nm
Memory
- Internal memory: 8 GB
- Internal memory type: DDR4-SDRAM
Storage
- Internal storage capacity: 256 GB
- Card reader integrated: No
- Compatible memory cards: Not supported
- Storage media: SSD
Graphics
- Graphics card family: Intel
- Graphics card: UHD Graphics 620
Camera
- Rear camera type: Single camera
- Rear camera resolution (numeric): 8 MP
- Auto focus: Yes
- Front camera: Yes
Network
- Bluetooth: Yes
- Bluetooth version: 5.0
- Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
- Wi-Fi standards: Wi-Fi 5 (802.11ac)
Ports & interfaces
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
- HDMI ports quantity: 1
- Combo headphone/mic port: Yes
- DC-in jack: Yes
Design
- Form factor: Slate
- Product colour: Black
- Device type: Tablet PC
- International Protection (IP) code: IP65
Performance
- Trusted Platform Module (TPM): Yes
Security
- Cable lock slot: Yes
- Cable lock slot type: Kensington
Software
- Platform: Windows
- Operating system installed: Windows 10 Pro
Processor special features
- Intel TSX-NI: No
- Intel® Identity Protection Technology (Intel® IPT): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel® Hyper Threading Technology (Intel® HT Technology): Yes
- Intel Virtualization Technology (VT-x): Yes
- Idle States: Yes
- Intel® Turbo Boost Technology: 2.0
- Intel® OS Guard: Yes
- Intel Software Guard Extensions (Intel SGX): Yes
- Intel Secure Key Technology version: 1.00
- Intel Enhanced Halt State: Yes
- Intel Smart Response Technology version: 1.00
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Embedded options available: No
- Intel Clear Video Technology: Yes
- Intel® Quick Sync Video Technology: Yes
- Intel® Smart Response Technology: Yes
- Intel Trusted Execution Technology: No
- Intel Flex Memory Access: Yes
- Intel TSX-NI version: 0.00
- Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID): Yes
- Intel 64: Yes
- Intel Identity Protection Technology version: 1.00
- Intel® Clear Video HD Technology (Intel® CVT HD): Yes
- Intel Stable Image Platform Program (SIPP): No
- Intel® My WiFi Technology (Intel® MWT): Yes
- Enhanced Intel SpeedStep Technology: Yes
- Intel® Secure Key: Yes
- Execute Disable Bit: Yes
- Intel Stable Image Platform Program (SIPP) version: 0.00
Battery
- Battery technology: Lithium-Ion (Li-Ion)
- Battery capacity: 4200 mAh
- Battery voltage: 11.1 V
Power
- AC adapter power: 65 W
- AC adapter input voltage: 100-240 V
- AC adapter frequency: 50 - 60 Hz
Weight & dimensions
- Width: 276.8 mm
- Depth: 194.5 mm
- Height: 23.5 mm
- Weight: 1220 g
Operational conditions
- Operating temperature (T-T): -29 - 63 °C
- Storage temperature (T-T): -51 - 71 °C
- Operating relative humidity (H-H): 0 - 95 %
Other features
- Processor socket: BGA 1528
- Processor ARK ID: 149088
