TAKING THE 105SL PLUS TO A NEW LEVEL WITH EXPANDED PERFORMANCE AND VALUE
Building on the legacy of the industry-leading, 105SLPlus printer, the ZT510 includes the core features you need in an industrial printer at a cost-effective price point. The ZT510 provides a proven, durable design and construction while adding advanced management and monitoring capabilities. That means you get 24/7 reliability to keep your operations running smoothly today, plus longevity and advanced functionality to power through every challenge in the years to come — all at an exceptional value.
EXCEPTIONAL PERFORMANCE IN THE HARSHEST CONDITIONS
Boost your productivity with printers that just won’t quit. The ZT510 builds on the legacy of its industry-leading predecessor, the 105SLPlus. Durable steel structural components can withstand years of abuse in extreme temperatures, dust, debris and other challenging industrial conditions, and meticulously engineered printing mechanisms provide 24/7 reliability to meet your high-volume production needs.
OPERATIONAL VISIBILITY, REMOTE MANAGEMENT AND FUTURE-READY ADAPTABILITY
Zebra’s cloud-accessible Link-OS software platform and managed services offerings give you total visibility and control over your printing systems, whether you’re onsite or across the globe. Plus, with two available communication slots, field-installable media-handling options and optional USB Host for plug-and-play integration, it’s easy to stay ahead of your evolving business and technology needs, whatever they may be.
A VALUE THAT WON'T BREAK YOUR BUDGET
For cost-conscious decision makers, the ZT510 offers next-generation print performance at an exceptional value. It provides high-duty cycle, rugged reliability, fast processing, advanced Link-OS capabilities and all the basic features you need — without the added cost of those you don’t.
Printing
- Print technology: Thermal transfer
- Colour: No
- Maximum resolution: 203 x 203 DPI
- Print speed: 305 mm/sec
- Maximum printing width: 104 mm
Paper handling
- Ribbon width: 110 mm
- Ribbon length: 450 m
- Media thickness: 0.076 x 0.305 mm
- Maximum roll diameter: 203 mm
Ports & interfaces
- Ethernet LAN: Yes
- Wi-Fi: No
- Bluetooth: Yes
- USB port: Yes
- USB 2.0 ports quantity: 1
Performance
- Built-in barcodes: Code 11,Code 128 (A/B/C),Code 39,Code 93,Data Matrix,EAN13,EAN8,MaxiCode,QR Code,TLC39,UPC-A,UPC-E
Design
- Product colour: Grey
- Built-in display: Yes
- Display: LCD
Operational conditions
- Operating relative humidity (H-H): 20 - 85 %
- Storage relative humidity (H-H): 20 - 85 %
- Operating temperature (T-T): 5 - 40 °C
- Storage temperature (T-T): -30 - 60 °C
Weight & dimensions
- Width: 268.2 mm
- Depth: 512.3 mm
- Height: 395.7 mm
- Weight: 22700 g
Logistics data
- Harmonized System (HS) code: 84433210
Technical details
- Sustainability certificates: ENERGY STAR
