With a range of specialised features and print resolution up to 300dpi, the TD-2130N is the perfect label printer for warehousing, logistics, manufacturing and retail – plus any other sector where you need to be able to print high-quality receipts or labels at your desk or on the move.
Printing
- Print technology: Direct thermal
- Maximum resolution: 300 x 300 DPI
- Print speed: 152.4 mm/sec
- Maximum printing width: 56 mm
- Vertical printing: Yes
Paper handling
- Autocutter: Yes
- Ribbon length: 1 m
- Maximum label length: 1 m
Ports & interfaces
- Connectivity technology: Wired
- Ethernet LAN: Yes
- Wi-Fi: No
- USB port: Yes
- USB 2.0 ports quantity: 1
- RS-232 ports: 1
- Optional connectivity: Bluetooth,Wireless LAN
Performance
- Page description languages: ESC P
- Internal memory: 32 MB
- Flash memory: 16 MB
- Built-in barcodes: 2D,CODABAR (NW-7),Code 128 (A/B/C),Code 39,Data Matrix,EAN13,EAN8,GS1 DataBar,GS1-128,ITF,MaxiCode,Micro QR Code,MicroPDF417,PDF417,QR Code,UPC-A,UPC-E
- Number of fonts: 10
- Tape cutting: Automatic
- Underline: Yes
- Security algorithms: 128-bit WEP,64-bit WEP,EAP-TLS,EAP-TTLS,LEAP,PEAP,SSID,TKIP,WPA-PSK,WPA2-PSK
Design
- Product colour: Black,Grey
- Built-in display: Yes
- Display: LCD
- Control type: Buttons
Power
- AC adapter output voltage: 25 V
- AC adapter output current: 6 A
System requirements
- Minimum storage drive space: 70 MB
- Minimum RAM: 128 MB
- Windows operating systems supported: Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows 8 Enterpr
- Server operating systems supported: Windows Server 2003,Windows Server 2008,Windows Server 2008 R2,Windows Server 2012
Operational conditions
- Operating relative humidity (H-H): 20 - 80 %
- Storage relative humidity (H-H): 20 - 80 %
- Storage temperature (T-T): -20 - 60 °C
- Operating temperature (T-T): 5 - 40 °C
Weight & dimensions
- Width: 285 mm
- Depth: 185 mm
- Height: 265 mm
- Weight: 2121 g
Packaging data
- Package weight: 2833 g
Packaging content
- Cables included: AC,USB
- Drivers included: Yes
- AC adapter included: Yes
Logistics data
- Harmonized System (HS) code: 84433210
- Pallet gross height: 157.5 mm
- Pallet gross weight: 294000 g
- Master (outer) cases per pallet: 30 pc(s)
- Master (outer) cases per pallet layer: 6 pc(s)
- Layers per pallet: 5 pc(s)
- Products per pallet: 90 pc(s)
Technical details
- Pallet type: 1200 x 1000 mm
Other features
- Spare part retention: 5 year(s)
- Character sets: Abicomp,ASCII,BRASCII,ISO 8859-15,ISO Latin 1,Italic,PC437,PC850,PC858,PC860,PC861,PC863,PC865,Roman 8
- Country of origin: China
- LED indicators: Yes
