With built-in network connectivity, the TD-4420DN is designed to be shared. Labels are printed at a high-resolution, producing sharp and clear images. Making the TD-4420DN ideal for printing 1D barcodes for scanning. Direct thermal print technology produces accurate images, with crisp definition. Utilising heat-sensitive coating, ink is not required. A good choice for printing high-volume, temporary labels with barcodes with a maximum media width up to 118mm/4.65 inches wide.
Printing
- Print technology: Direct thermal
- Colour: No
- Maximum resolution: 203 x 203 DPI
- Print speed: 203 mm/sec
- Print speed: 8 lpm
- Maximum print height: 104 mm
- Mirror printing: Yes
- Text style: Bold,Horizontal lines,Invert,Italic,Normal,Shadow,Shadow light,Surround
- Maximum print length: 3 m
Paper handling
- Maximum roll diameter: 127 mm
- Core diameter: 12.7 mm
- Maximum label width: 118 mm
Ports & interfaces
- Connectivity technology: Wired
- Ethernet LAN: Yes
- Wi-Fi: No
- Bluetooth: No
- USB port: Yes
- USB 2.0 ports quantity: 1
- RS-232 ports: 1
Performance
- Page description languages: ESC P,Raster_P,ZPL II
- Internal memory: 256 MB
- Flash memory: 64 MB
- Number of fonts: 6
- Font styles: Brougham,Brussels,Helsinki,Letter Gothic,San Diego
Design
- Product colour: Grey,White
- Built-in display: No
- Display: No
Power
- Auto power off: Yes
System requirements
- Mobile operating systems supported: Android 4.1,Android 4.2,Android 4.2.1,Android 4.2.2,Android 4.3,Android 4.4,Android 5.0,Android 5.1,Android 6.0,Android 7.0,Android 7.1,Android 7.1.2,Android 8.0,Android 9.0,iOS 10.0,iOS 11.0,iOS 12,iOS 8.0,iOS 8.1,iOS 8.2,iOS 8.3,iOS 8.4,iOS 9.0,iOS 9.1,
- Linux operating systems supported: Yes
- Server operating systems supported: Windows Server 2008,Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016
- Windows operating systems supported: Windows 10,Windows 7,Windows 8,Windows 8.1
Operational conditions
- Operating relative humidity (H-H): 5 - 40 %
- Storage relative humidity (H-H): 20 - 85 %
- Storage temperature (T-T): -20 - 60 °C
- Operating temperature (T-T): 10 - 90 °C
Weight & dimensions
- Width: 265 mm
- Depth: 335 mm
- Height: 256 mm
- Weight: 3097 g
Packaging data
- Quantity per pack: 1 pc(s)
- Package weight: 4021 g
Packaging content
- Cables included: AC,USB
- Warranty card: Yes
- AC adapter included: Yes
- Starter roll included: Yes
- Software development kit (SDK): Yes
- Quick start guide: Yes
Logistics data
- Harmonized System (HS) code: 84433210
- Pallet gross height: 143 mm
- Pallet gross weight: 176400 g
- Master (outer) cases per pallet: 40 pc(s)
- Master (outer) cases per pallet layer: 8 pc(s)
- Layers per pallet: 5 pc(s)
- Products per pallet: 40 pc(s)
Technical details
- Pallet type: 800 x 1200 mm
Other features
- Date & time printing: Yes
- LED indicators: Error,Power,Status
- Languages support: CHI (SIMPL),CZE,DAN,DEU,DUT,ENG,ESP,FIN,FRE,HUN,ITA,JPN,NOR,POL,POR,RUS,SWE,TUR
- Country of origin: China
- Number of languages: 18
- Spare part retention: 5 year(s)
