Easy, Seamless Connectivity
- Compatible with all major operating systems including Android™, iOS® and Windows®
- Dual-band WLAN (5Ghz and 2.4 GHz)
- Dual-mode Bluetooth V4.1 Classic (MFi AP2 certified) and LE
- Easy Bluetooth pairing via NFC
- Smart Wi-Fi setting via mobile devices
- SoftAP enables direct connection to mobile devices
Enhanced Optimization for Field Service
- Compact, ergonomic and light-weight (530g)
- 1.8 m / 6 ft. drop rate
- IP54 (Printer only) water and dust proof
- 56-hour stand by time once fully charged(Bluetooth model in power save mode)
- Supports continuous printing - 6 rolls of 57 mm diameter paper (Total 162 m) once fully charged
- Supports a wide range of carrying and charging accessories
Multi-Purpose Design
- Fast printing speed up to 90 mm/sec (Receipt)
- Transmissive gap sensor - supports front and back sensors (Optional Positioning)
- Easily switch from receipt to label printing using feed button or VMSM software(No hardware change needed)
- Supports linerless label printing (optional)
Printing
- Print technology: Direct thermal
- Type: Mobile printer
- Maximum resolution: 203 x 203 DPI
- Print speed: 90 mm/sec
- Character size: 24 x 24 mm
Paper handling
- Supported paper width: 112 mm
- Maximum printing width: 104 mm
- Printing media thickness: 57 µm
- Maximum roll diameter: 57 mm
Ports & interfaces
- Connectivity technology: Wired & Wireless
- USB port: Yes
- USB 2.0 ports quantity: 1
- Serial interface: Yes
- Standard interfaces: Serial,USB 2.0
- Serial ports quantity: 1
Network
- Ethernet LAN: No
- Wi-Fi: Yes
Features
- Internal memory: 64 MB
- Flash memory: 32 MB
- Linear (1D) barcodes supported: Codabar,Code 128,Code 128A,Code 128B,Code 128C,Code 39,Code 93,EAN-13,EAN-8,U.P.C.
Design
- Product colour: Black
Power
- Battery technology: Lithium-Ion (Li-Ion)
- Battery recharge time: 4 h
- Battery voltage: 7.4 V
Operational conditions
- Operating temperature (T-T): -15 - 50 °C
- Operating relative humidity (H-H): 10 - 80 %
- Storage temperature (T-T): -30 - 70 °C
Weight & dimensions
- Width: 143 mm
- Depth: 138 mm
- Height: 66 mm
- Weight: 242 g
Other features
- International Protection (IP) code: IP54
