Scanning
- Type: Fixed bar code reader
- Scanner type: 1D/2D
- Linear (1D) barcodes supported: Code 128,Code 39,Code 93
- Sensor type: CMOS
- 2D (matrix & stacked) barcodes supported: Aztec Code,Data Matrix,Han Xin,MaxiCode,Micro QR Code,MicroPDF417,QR Code,TLC-39
- Laser guide: No
- Trigger mode: Auto-induction
- Optical sensor resolution (W x H): 1920 x 1200 pixels
- 2D resolution (min): 5 mm
- 1D resolution (min): 3 mm
- Working distance: 230 mm
- Horizontal field of view: 54 °
- Vertical field of view: 35.5 °
- Wavelength: 660 nm
Ports & interfaces
- Connectivity technology: Wired
- Standard interfaces: Keyboard wedge,RS-232,RS-485,USB
Performance
- Product colour: Black
- Housing material: Plastic
- International Protection (IP) code: IP52
Power
- Power source type: USB
- Power consumption (typical): 2.4 W
- Power consumption (standby): 1.2 W
- Input voltage: 5 V
Weight & dimensions
- Width: 152 mm
- Depth: 86 mm
- Height: 152 mm
- Weight: 834 g
