With its compact, modern design and powerful imaging capabilities built on Honeywell’s extreme performance (XP) platform, the Solaris 7990g fits easily into existing enclosures used in high-volume retail checkout environments such as convenience, drug, specialty, liquor and grocery stores. The Solaris XP features 20% faster scanning speed, up to 5 m/s motion tolerance, and a wider field of view than previous Solaris models. Honeywell’s field proven XP technology handles poorly printed and damaged barcodes with ease. The Solaris XP is backwards compatible with previous models, making upgrades fast and simple.
Scanning
- Type: Fixed bar code reader
- Scanner type: 1D/2D
- 2D (matrix & stacked) barcodes supported: QR Code,Data Matrix,PDF417,Aztec Code
- Sensor type: CMOS
- Linear (1D) barcodes supported: Code 39 (ASCII),Code 128,EAN-13,EAN-8,UPC-A,UPC-E,Codabar,Interleaved 2 of 5
- Working distance: 1000 mm
- Read rate (max): 6 reads/s
- Light levels (direct sunlight): 0 - 100000 lx
Ports & interfaces
- Connectivity technology: Wired
- Standard interfaces: USB,RS-232
Performance
- Product colour: Black
- International Protection (IP) code: IP53
Power
- Power source type: AC
- Input voltage: 5.2 V
Weight & dimensions
- Width: 152 mm
- Depth: 85 mm
- Height: 148 mm
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 95 %
