- Compact desktop printer for 74 m ribbon.
- Label printer for Android mobile devices.
- Wireless shipping label printer.
- Wristband printer.
- 1D and 2D Barcode printer.
Flexible to Use.
- Compatible with Android-based smart devices.
- Triple interface supported: USB + Serial + Parallel.
- Optional Ethernet and WLAN supported (USB dongle type).
Outstanding Form Factor.
- Fast printing speed up to 7 ips (178 mm/sec).
- Quick data processing through powerful memory.
- Compact design for 74m ribbon.
- Energy-efficient product.
Intelligent Function.
Smart Media Detection is Bixolon’s world-class technology that detects label length and media types such as gap media, black mark media, and short length media paper. Intelligent Leap-over™ detects empty label and automatically leaps to the next label.
Premium-level Compatibility.
Fully compatible with market-leading programming languages.
User-friendly Design.
- Various type of media sensor supported.
- Easy paper loading with adjustable paper guide.
- Simple to change ribbon, thermal print head, and roller.
Label Artist.
Bixolon provides its custom label design program as bundle. It supports database connection as well as text, drawing lines and boxes, all kinds of graphics and 1D/2D Barcode printing.
Printing
- Print technology: Direct thermal / thermal transfer
- Colour: No
- Maximum resolution: 300 x 300 DPI
- Print speed: 127 mm/sec
- Maximum printing width: 105.7 mm
- Maximum print height: 2000 mm
Paper handling
- Ribbon width: 110 mm
- Ribbon length: 74 m
- Supported paper width: 20 - 110 mm
- Core diameter: 12.7 mm
- Media thickness: 0.06 - 0.20 mm
- Maximum roll diameter: 130 mm
Ports & interfaces
- Connectivity technology: Wired
- Ethernet LAN: Yes
- Wi-Fi: No
- USB port: Yes
- USB 2.0 ports quantity: 2
- RS-232 ports: 1
- Optional connectivity: Wireless LAN
Performance
- Internal memory: 64 MB
- Flash memory: 128 MB
- Built-in barcodes: 1D,2D,AZTECCODE,CODABAR (NW-7),Code 11,Code 128 (A/B/C),Code 39,Code 49,Code 93,Data Matrix,EAN13,EAN8,GS1 DataBar,IMB,Industrial 2/5,Interleaved 2/5,MaxiCode,MicroPDF417,PDF417,POSTNET,QR Code,TLC39,UPC-A,UPC-E
Design
- Product colour: Grey
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
System requirements
- Windows operating systems supported: Yes
Operational conditions
- Operating relative humidity (H-H): 10 - 80 %
- Storage relative humidity (H-H): 10 - 90 %
- Operating temperature (T-T): 5 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
- Width: 200 mm
- Depth: 252 mm
- Height: 173 mm
- Weight: 2350 g
Logistics data
- Harmonized System (HS) code: 84433210
Technical details
- Sustainability certificates: ENERGY STAR
Other features
- Emulations: SLCS, BPL-Z, BPL-E
