Compact desktop printer for 74 m ribbon
Label printer for Android mobile devices
Wireless shipping label printer
Wristband printer
1D and 2D Barcode printer
Flexible to Use
- Compatible with Android-based smart devices
- Triple interface supported: USB + Serial + Parallel
- Optional Ethernet and WLAN supported (USB dongle type)
Outstanding Form Factor
- Fast printing speed up to 7 ips (178 mm/sec)
- Quick data processing through powerful memory
- Compact design for 74m ribbon
- Energy-efficient product
Intelligent Function
Smart Media Detection™ is Bixolon’s world-class technology that detects label length and media types such as gap media, black mark media, and short length media paper. Intelligent Leap-over™ detects empty label and automatically leaps to the next label.
Premium-level Compatibility
Fully compatible with market-leading programming languages
User-friendly Design
- Various type of media sensor supported
- Easy paper loading with adjustable paper guide
- Simple to change ribbon, thermal print head, and roller
Label Artist™
Bixolon provides its custom label design program as bundle. It supports database connection as well as text, drawing lines and boxes, all kinds of graphics and 1D/2D Barcode printing.
Printing
- Print technology: Direct thermal / thermal transfer
- Colour: No
- Maximum resolution: 203 x 203 DPI
- Print speed: 178 mm/sec
- Printing colours: Black
- Maximum printing width: 108 mm
- Minimum print length: 6 mm
Paper handling
- Ribbon length: 74 m
- Maximum roll diameter: 130 mm
- Supported paper width: 20 - 110 mm
- Media thickness: 0.06 - 0.2 mm
Ports & interfaces
- Connectivity technology: Wired & Wireless
- Ethernet LAN: No
- Wi-Fi: No
- Bluetooth: Yes
- USB port: Yes
- USB 2.0 ports quantity: 1
- Parallel ports quantity: 1
- RS-232 ports: 1
Performance
- Page description languages: BPL
- Internal memory: 64 MB
- Flash memory: 128 MB
- Built-in barcodes: 1D,AZTECCODE,CODABAR (NW-7),Code 11,Code 39,Code 93,Code-128 Codabar Library,Data Matrix,EAN13,EAN8,GS1 DataBar,IMB,Industrial 2/5,Interleaved 2/5,MaxiCode,MicroPDF417,PDF417,POSTNET,QR Code,TLC39,UPC-A,UPC-E
Design
- Product colour: Black,Grey
- Built-in display: No
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
System requirements
- Mac operating systems supported: Yes
- Windows operating systems supported: Yes
- Linux operating systems supported: Yes
Operational conditions
- Operating relative humidity (H-H): 10 - 80 %
- Storage relative humidity (H-H): 10 - 90 %
- Storage temperature (T-T): -20 - 60 °C
- Operating temperature (T-T): 5 - 40 °C
Weight & dimensions
- Width: 200 mm
- Depth: 252 mm
- Height: 173 mm
- Weight: 2350 g
Packaging content
- Manual: Yes
- AC adapter included: Yes
- Drivers included: Yes
Logistics data
- Harmonized System (HS) code: 84433210
Technical details
- Sustainability certificates: ENERGY STAR
Other features
- LED indicators: Yes
