- Wristband Printer
- Order Label Printer
- Barcode Printer
Advanced Performance
- Printing speed up to 6 ips (152 mm/s)
- Fast data processing speed of various types of label
Smart Media Detection™
- Automatic paper detection such as gap media, black mark media and short length media paper
Dual interface
- Standard: Serial + USB
- Optional: Ethernet + WLAN* + USB
User-friendly Design
- Easy paper loading with adjustable paper guide
- Pause and cancel function-keys
Powerful Compatibility
The SLP-DX220 is fully compatible with market-leading programming language; SLCS, BPL-Z™, BPL-E™.
Label Artist™
Bixolon provides its custom label design program as bundle. It supports database connection as well as text, drawing lines and boxes, all kinds of graphics and 1D/2D Barcode printing.
Printing
- Print technology: Direct thermal
- Colour: No
- Maximum resolution: 203 x 203 DPI
- Print speed: 152 mm/sec
- Printing colours: Black
- Maximum printing width: 54 mm
- Minimum print length: 6 mm
- Maximum print length: 2 m
Paper handling
- Media thickness: 0.06 - 0.20 mm
- Maximum roll diameter: 130 mm
- Supported paper width: 15 - 60 mm
Ports & interfaces
- Connectivity technology: Wired & Wireless
- Ethernet LAN: Yes
- Wi-Fi: No
- Bluetooth: Yes
- RS-232 ports: 1
Performance
- Page description languages: BPL
- Internal memory: 64 MB
- Flash memory: 128 MB
- Built-in barcodes: 1D,2D,AZTECCODE,CODABAR (NW-7),Code 11,Code 39,Code 93,Code-128 Codabar Library,Data Matrix,EAN13,EAN8,GS1 DataBar,IMB,Industrial 2/5,Interleaved 2/5,MicroPDF417,PDF417,POSTNET,QR Code,TLC39,UPC-A,UPC-E
Design
- Product colour: Grey
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
Operational conditions
- Operating relative humidity (H-H): 0 - 40 %
- Storage relative humidity (H-H): -20 - 60 %
- Storage temperature (T-T): 10 - 90 °C
- Operating temperature (T-T): 10 - 80 °C
Weight & dimensions
- Width: 120 mm
- Depth: 230 mm
- Height: 170 mm
- Weight: 1360 g
Logistics data
- Harmonized System (HS) code: 84433210
Technical details
- Sustainability certificates: ENERGY STAR
Other features
- Navigation key: Yes
- LED indicators: Yes
