RS6100 Wearable Scanner, SE55, Standard Battery, Single Trigger,
0C to +50C Operation, Worldwide
Introducing Zebra’s most powerful and versatile wearable scanner — the RS6100. This small and practically weightless wearable scanner is less than half the size and weight of its predecessor, the RS6000. An advanced multi-focus scan engine captures 1D and 2D barcodes at close range and on the top shelf of a rack 40 ft./12.2 m away, regardless of condition — scratched, dirty, poorly printed, under shrinkwrap and more. With five interchangeable wearing options, there’s a style that will maximize comfort for every user. Use it anywhere — from warehouse aisles, freezers and coolers to the seat of a fork truck and out on the dock in rain, snow, blazing summer heat or subzero winter cold. The RS6100 is always in service with its removable battery — no downtime needed for charging, just swap in a fully charged battery. Choose cordless freedom with two battery options or corded battery-free operation. And since the RS6100 and RS5100 share common trigger assemblies, batteries and mounts, upgrading from the RS5100 is easy and cost-effective.
Scanning
- Type: Wearable bar code reader
- Scanner type: 2D
- Linear (1D) barcodes supported: Codabar,Code 128,Code 39,Code 93,MSI,Standard 2 of 5
- Sensor type: LED
- 2D (matrix & stacked) barcodes supported: Aztec Code,Chinese Sensible Code,Composite Codes,Data Matrix,MaxiCode,Micro QR Code,MicroPDF417,PDF417,QR Code,TLC-39
- Optical sensor resolution (W x H): 2688 x 1520 pixels
- Light levels (direct sunlight): 107.639 - 107.639 lx
- Wavelength: 515 nm
- Pitch reading angle: 60 - 60 °
- Yaw reading angle: 60 - 60 °
Ports & interfaces
- Connectivity technology: Wired & Wireless
- Standard interfaces: Bluetooth
- Bluetooth version: 5.2
- Bluetooth Low Energy (BLE): Yes
- Near Field Communication (NFC): Yes
Performance
- Product colour: Grey,Yellow
- International Protection (IP) code: IP65
- Protection features: Drop resistant,Electrostatic Discharge (ESD) protection,Vibration proof
Power
- Power source type: Battery
Weight & dimensions
- Width: 66.6 mm
- Depth: 32.7 mm
- Height: 21 mm
Operational conditions
- Storage temperature (T-T): -40 - 70 °C
- Operating temperature (T-T): -30 - 50 °C
- Operating relative humidity (H-H): 5 - 95 %
- Drop resistance: 1.8 m
Technical details
- Warranty period: 1 year(s)
- Compliance certificates: REACH,RoHS
