The Power-over-Ethernet (POE) module offers a convenient and cost effective way to deliver power to the Android I-Series. The module allows you to put a DC voltage onto specific pairs of the Ethernet cable so that devices connected to the network can use it as a power source. So instead of requiring a power drop which can be expensive, you can run a low voltage network to simplify installation of solutions for shelf signage and AV applications like conference room schedulers or AV control displays.
Network
- Networking standards: IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3bt,IEEE 802.3af
- Cable types supported: Cat5
Features
- Product colour: Black
- Power protection features: Over current,Overheating
Power
- Efficiency: 85 %
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 20 - 80 %
- Storage temperature (T-T): -20 - 70 °C
- Storage relative humidity (H-H): 10 - 95 %
Weight & dimensions
- Width: 115 mm
- Depth: 115 mm
- Height: 18.8 mm
- Weight: 119 g
Packaging data
- Package width: 180 mm
- Package depth: 145 mm
- Package height: 42 mm
- Package weight: 232 g
Technical details
- Compliance certificates: Federal Communications Commission (FCC),Industry Canada (IC),CE,VCCI,RCM
