The PC45T thermal transfer printer brings powerful performance, flexible configuration, reliable connectivity, and easy integration in a compact design to tackle rapidly changing everyday work environments.
PC45T is a 4-inch thermal transfer desktop printer that offers a large touch screen, enterprise-level ruggedness, and multiple new design accessories to support various needs. The PC45T is designed with flexibility in mind, allowing businesses to easily change between thermal transfer and direct thermal media.
Honeywell Printer Edge™ platform provides a centralized management system for your printer network. Allowing real-time visibility, automated software updates, and enhanced security. This efficient and cost effective solution for businesses looking to optimize printer operations, Honeywell Printer Edge streamlines workflows and helps reduce downtime, making it easier for you to manage costs.
Get connected and stay connected with Wi-Fi 5 and Bluetooth 5.1 LE for continuous productivity. Benefit from WLAN and optional WWAN connectivity for fast data capture allowing for accelerated deployments. With optional low media and low ribbon enabled sensor and RFID, take the guesswork out printer maintenance to avoid unnecessary operational downtime.
Whether on a local server or utilizing the Cloud, the PC45 supports variable network protocols and multiple print languages allowing for easy integration and a seamless transition. Smart Parse technology from Honeywell gives the ability to resize objects, barcodes, or font type without any need to get in on the system backend. Honeywell Operational Intelligence takes it one step further providing remote management capabilities for real-time diagnostics and output performance tracking.
Printing
- Print technology: Thermal transfer
- Colour: No
- Maximum resolution: 203 x 203 DPI
- Print speed: 8 lpm
- Maximum printing width: 108 mm
- Printing characters: Barcode
Paper handling
- Maximum label width: 108 mm
- Maximum roll diameter: 127 mm
- Media thickness: 0.05 - 0.16 mm
- Core diameter: 38.1 mm
- Maximum media length: 6.35 mm
Ports & interfaces
- Connectivity technology: Wired & Wireless
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Wi-Fi standards: 802.11a,802.11b,802.11g,Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
- Bluetooth: Yes
- Bluetooth version: 5.2
- USB port: Yes
- USB 2.0 ports quantity: 1
- RS-232 ports: 1
Performance
- Page description languages: DP,DPL,XML,ZPL II,IPL,PDF
- Internal memory: 256 MB
- Flash memory: 512 MB
- Built-in barcodes: QR Code
- Built-in RFID module: Yes
- Security algorithms: LEAP,PEAP,TLS,TTLS,WEP,WPA,WPA2,WPA3
Design
- Product colour: Black
- Built-in display: Yes
- Display: LCD
- Display diagonal: 3.5 "
- Display resolution: 320 x 240 pixels
- Colour display: Yes
- Backlight display: Yes
- Control type: Buttons
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- AC adapter output voltage: 24 V
- AC adapter output current: 3.15 A
- Power source type: DC
System requirements
- Linux operating systems supported: Yes
- Windows operating systems supported: Yes
Operational conditions
- Storage relative humidity (H-H): 10 - 90 %
- Storage temperature (T-T): -20 - 70 °C
- Operating temperature (T-T): 0 - 45 °C
Weight & dimensions
- Width: 212.9 mm
- Depth: 179.6 mm
- Height: 285.5 mm
- Weight: 2700 g
Technical details
- Sustainability certificates: ENERGY STAR
- Compliance certificates: CE,Federal Communications Commission (FCC),RoHS
- Sustainability compliance: Yes
