Datalogic Magellan 3550HSi, Built-in bar code reader, 1D/2D, Laser, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, PDF417, Aztec Code, Data Matrix, QR Code, 1280 x 1024 pixels

DATALOGICSKU: M3551-010300
Magellan 3550HSi, Scanner, Multi-Interface, 1D/2D Model with Digimarc, Sapphire Glass (Mount and Required Cable and/or Power Accessories Sold Separately)-

Pris:
Reapris6,763.54 kr eks. mva.
Lager:
Preliminärt i lager

The Magellan 3550HSi scanner offers many of the features that have made the Magellan family of imaging scanners so successful, including seamless 1D and 2D decoding, solid state electronics, image capture, compact size and easy service access for software updates or configuration changes.  It also benefits from the advances made in imaging, illumination, processors and software that Datalogic has brought to the multi-plane market with the Magellan 9800i and 9400i scanners.
Improvements in both hardware and software enable a significant reduction in the brightness of the illumination while improving throughput, depth of field, and speed to read.  The gentle, unobtrusive illumination reduces both direct and reflected illumination visible to users.  This ensures a comfortable work environment and all day productivity.  The Magellan 3550HSi scanner also has a larger, more intuitive scan zone, enabling more comfortable and efficient sweep scanning.

Scanning

  • Type: Built-in bar code reader
  • Scanner type: 1D/2D
  • Sensor type: Laser
  • 2D (matrix & stacked) barcodes supported: Aztec Code,Data Matrix,QR Code
  • Linear (1D) barcodes supported: GS1 DataBar,GS1 DataBar Expanded,GS1 DataBar Omnidirectional,PDF417
  • Optical sensor resolution (W x H): 1280 x 1024 pixels
  • Working distance: 102 mm
  • Read rate (max): 39000000 reads/s
  • Tilt reading angle: 0 - 360 °
  • Pitch reading angle: -65 - 65 °
  • Yaw reading angle: -75 - 75 °

Ports & interfaces

  • Connectivity technology: Wired
  • Standard interfaces: RS-232,USB

Performance

  • Product colour: Black,Stainless steel
  • International Protection (IP) code: IP52
  • Built-in display: No
  • Ambient lighting: Yes
  • Print contrast: 25 %
  • Compatible memory cards: MicroSD (TransFlash)

Power

  • Power source type: DC
  • Power consumption (typical): 3 W
  • Power consumption (standby): 4 W
  • Input voltage: 12 V
  • Input frequency: 50/60 Hz
  • AC adapter output voltage: 100 - 240 V

Weight & dimensions

  • Width: 152 mm
  • Depth: 87 mm
  • Height: 152 mm
  • Weight: 980 g

Operational conditions

  • Storage temperature (T-T): -40 - 70 °C
  • Operating temperature (T-T): 10 - 40 °C
  • Operating relative humidity (H-H): 5 - 95 %

Logistics data

  • Harmonized System (HS) code: 84716070
+
