Industrial label maker
Versatile label maker for high print volume users who value time-saving functionality.
This portable industrial label maker boasts PC, smart device and apps connectivity (USB, Ethernet, Wi-Fi, and Wi-Fi Direct) for ease of use at your desk or on the move. It's been developed for those working in data centres, maintenance, repair, overhaul (MRO), factories, warehouses, laboratories, construction, and electrical maintenance.
Versatile
It supports a wide range of media (from 4mm to 50mm width labels), including cartridges and big rolls; and many material types including resistance, regulation and market standard compliancy.
Flexible
The applications are as varied as the media choices: cabling and wiring, audio and video identification, asset management, and safety and security signs. They’re designed to save you time when setting, editing, printing and handling.
Time-saving
application (editing phase), fast print speeds and big (media) roll support. The LW-Z5000BE's portability means you’re able to print high volumes on the move.
Economical
Designed with a low total cost of ownership (TCO) in mind. Big rolls allow running costs to be cut down dramatically. A clear ROI should be seen within a few months. Also, enhancements made to setting, editing, printing and handling are designed to positively effect the overall TCO.
Printing
- Print technology: Thermal transfer
- Maximum resolution: 360 x 360 DPI
- Number of printable dots: 616 dot
- Print speed: 50 mm/sec
- Maximum printing width: 50 mm
- Maximum print height: 52 mm
- Margin depth settings: 1mm,Auto,Fixed,Manual
- Wire wrap printing: Yes
- Flag style printing: Yes
- Mirror printing: Yes
- Vertical printing: Yes
- Text style: Bold,Italic,Shadow,Normal,Invert,Outline,Strikethrough,Underline
- Text alignment: Center,Justify,Left,Manual,Right
Paper handling
- Autocutter: Yes
- Half-cutter: Yes
Ports & interfaces
- Connectivity technology: Wired & Wireless
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Wi-Fi standards: 802.11b,802.11g,Wi-Fi 4 (802.11n)
- USB port: Yes
Performance
- Built-in barcodes: Code 128 (A/B/C),Code 39,Data Matrix,EAN128,EAN13,EAN8,GS1-128,GS1 DataBar,ITF,MaxiCode,PDF417,QR Code,UPC-A,UPC-E
- Number of symbols: 466
- Fixed length: Yes
- Tape width: 50 mm
- Pick & Print function: Yes
- Drop Stop function: Yes
- Reset types: Software reset
- Units supported: mm,inch
- Alphanumeric memory: Depends on the user's PC
- Number of printing lines (max): Variable
- Tape size detection: Yes
- Tape end detection: Yes
- Open cover detection: Yes
Power
- Power consumption (printing): 29 W
- Power consumption (off): 0.23 W
- Auto power off: Yes
System requirements
- Minimum display resolution requirement: 1024 x 768 pixels
- Compatible operating systems: Android 4.0+, Windows 10, Windows 10 (32/64 bit), iOS 6.0+
- Minimum storage drive space: 100 MB
Weight & dimensions
- Width: 193 mm
- Depth: 198 mm
- Height: 144 mm
- Weight: 2900 g
Packaging data
- Quantity per pack: 1 pc(s)
- Package width: 285 mm
- Package depth: 390 mm
- Package height: 325 mm
- Package weight: 5816 g
Packaging content
- Cables included: AC
- Warranty card: Yes
- Bundled software: Epson Label Editor
- AC adapter included: Yes
Logistics data
- Harmonized System (HS) code: 84433210
- Pallet weight (UK): 0 g
- Products per pallet (UK): 60 pc(s)
- Pallet gross weight: 0 g
- Products per pallet: 48 pc(s)
Technical details
- Handle(s): Yes
- Autoincrement: 0-9, a-z, A-Z, Alphabetic, Numerical, Date, Time
- Font size: Selectable
- Multi-block: Wählbar
- Feed button: 1
Other features
- Printing history: Yes
- Printing history features: Browsing
- Lanyard hole: Yes
- Number of tables: 8
- LED indicators: Power
- Number of frames: 86
- Country of origin: China
- Clock function: Yes
