Rugged, cordless
Scanning
- Type: Handheld bar code reader
- Scanner type: 1D
- Linear (1D) barcodes supported: Codabar,Code 11,Code 128,Code 39,Code 93,GS1-128 (UCC/EAN-128),MSI,Plessey,U.P.C.
- 2D (matrix & stacked) barcodes supported: Not supported
- Wavelength: 617 nm
- Tilt reading angle: -65 - 65 °
- Pitch reading angle: -65 - 65 °
- Yaw reading angle: -45 - 45 °
- Optical sensor resolution: 1500 pixels
Ports & interfaces
- Connectivity technology: Wired & Wireless
- Standard interfaces: RS-232,USB,Keyboard wedge
- Wireless range: 100 m
- Bluetooth Low Energy (BLE): Yes
- Bluetooth version: 4.0
Performance
- Product colour: Black,Green
- International Protection (IP) code: IP67
- Protection features: Dust resistant,Shock resistant,Water resistant
- LED indicators: Yes
- Programming function: Yes
Power
- Power source type: Battery
- Battery technology: Lithium-Ion (Li-Ion)
- Battery capacity: 3100 mAh
- Number of reads per charge: 70000
Weight & dimensions
- Width: 142 mm
- Depth: 76 mm
- Height: 185 mm
- Weight: 385 g
Packaging data
- Cables included: USB
Operational conditions
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 5 - 95 %
- Operating temperature (T-T): -20 - 50 °C
Technical details
- Compliance certificates: RoHS
Logistics data
- Harmonized System (HS) code: 84716070
