Zebra FS20-SR10F3-2C00W, Fixed bar code reader, 1D/2D, CMOS, Code 93, Codabar, Code 128, MSI-Plessey, U.P.C., Code 39, Aztec Code, PDF417, Data Matrix, QR Code, Dot Code A, MaxiCode, Micro QR Code, MicroPDF417, 1280 x 800 pixels

ZEBRASKU: FS20-SR10F3-2C00W
FS20 Fixed Industrial Scanner, 7.76 oz./195 g

Pris:
Reapris15,627.08 kr eks. mva.
Lager:
Preliminärt i lager -

Easily integrate high quality scanning into your network
The increasing demands of international commerce and its global supply chain are pressuring companies to deliver more — and to do it faster. From manufacturing to logistics to the end customer, success is driven by the ability to quickly move and track the products that drive your business.

Address it all with the compact Zebra FS20 Fixed Industrial Scanner.1 With the FS20, it’s easy to track and trace every item as it moves through production, storage and fulfillment. Scan barcodes on components moving through your assembly line to ensure the right part is used at the right time — and enable rapid targeted recalls of products that contain defective parts. Scan barcodes on items as they are placed on warehouse shelves to provide visibility into real time inventory. And scan barcodes when fulfilling orders to ensure the right items are sent to the right customer. Whatever you want to track and trace, the FS20 makes it easy.

Scanning

  • Type: Fixed bar code reader
  • Scanner type: 1D/2D
  • 2D (matrix & stacked) barcodes supported: Aztec Code,PDF417,Data Matrix,QR Code,Dot Code A,MaxiCode,Micro QR Code,MicroPDF417
  • Sensor type: CMOS
  • Linear (1D) barcodes supported: Code 93,Codabar,Code 128,MSI-Plessey,U.P.C.,Code 39
  • Optical sensor resolution (W x H): 1280 x 800 pixels
  • Horizontal field of view: 35 °
  • Vertical field of view: 26 °

Ports & interfaces

  • Connectivity technology: Wired
  • Standard interfaces: RJ-45,RS-232
  • Ethernet LAN data rates: 10,100,1000 Mbit/s

Performance

  • Product colour: Black,Green
  • Housing material: Aluminium
  • International Protection (IP) code: IP65, IP67
  • Protection features: Vibration proof,Shock resistant
  • LED indicators: Yes

Power

  • Power source type: DC,PoE
  • Power consumption (typical): 7.5 W
  • Input voltage: 10 - 30 V
  • Power consumption: 313 mA

Weight & dimensions

  • Width: 54.6 mm
  • Depth: 94.2 mm
  • Height: 28.3 mm
  • Weight: 195 g

Operational conditions

  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 5 - 90 %
  • Operating temperature (T-T): 0 - 45 °C
+
