Display
- Display diagonal: 10.1 "
- Display resolution: 2560 x 1600 pixels
- Touchscreen type: Capacitive
- HD type: Full HD
Processor
- Processor manufacturer: Intel
- Processor family: Intel Atom®
- Processor model: x5-E3940
- Processor cores: 4
- Processor threads: 4
- Processor boost frequency: 1.8 GHz
- Processor frequency: 1.6 GHz
- Processor cache: 2 MB
- Processor cache type: L2
- Processor codename: Apollo Lake
- Processor operating modes: 64-bit
- Processor series: Intel Atom x5 Series
- Number of execution units: 12
- Processor package size: 24 x 31 mm
- Thermal Monitoring Technologies: Yes
- UART: Yes
- Conflict-Free processor: Yes
- Processor lithography: 14 nm
- Thermal Design Power (TDP): 9.5 W
- Tcase: 100 °C
- Tjunction: 110 °C
Memory
- Internal memory: 4 GB
- Internal memory type: DDR4-SDRAM
Storage
- Internal storage capacity: 64 GB
- Compatible memory cards: MMC
Camera
- Rear camera type: Single camera
- Rear camera resolution (numeric): 8 MP
- Front camera: Yes
- Front camera resolution (numeric): 2 MP
Network
- Mobile network connection: Yes
- Mobile network generation: 4G
- 4G standard: LTE
- Bluetooth: Yes
- Bluetooth version: 4.2
- Top Wi-Fi standard: 802.11b
- Wi-Fi standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n)
- Near Field Communication (NFC): Yes
Design
- Form factor: Slate
- Product colour: Black
- Device type: Tablet PC
- International Protection (IP) code: IP65
Performance
- Position location: Yes
- GLONASS: Yes
- Galileo: Yes
- GPS (satellite): Yes
Software
- Platform: Windows
- Operating system installed: Windows 10 IoT Enterprise
Processor special features
- Intel® Turbo Boost Technology: No
- Intel Rapid Storage Technology: No
- Intel Smart Connect Technology: No
- Embedded options available: Yes
- Intel® Secure Key: Yes
- Physical Address Extension (PAE): Yes
- Intel® High Definition Audio (Intel® HD Audio): Yes
- Intel® Identity Protection Technology (Intel® IPT): Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Intel® Clear Video HD Technology (Intel® CVT HD): Yes
- Intel Secure Boot: Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Execute Disable Bit: Yes
- Intel® Anti-Theft Technology (Intel® AT): No
- Enhanced Intel SpeedStep Technology: Yes
- Intel 64: Yes
- Intel® Quick Sync Video Technology: Yes
- Intel Clear Video Technology: Yes
- Intel® Hyper Threading Technology (Intel® HT Technology): No
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel® Smart Response Technology: No
- Intel® OS Guard: No
- Intel Trusted Execution Technology: No
- Intel Stable Image Platform Program (SIPP): No
- Idle States: Yes
- Physical Address Extension (PAE): 40 bit
Battery
- Battery technology: Lithium-Ion (Li-Ion)
- Battery capacity: 4950 mAh
- Battery capacity: 38 Wh
- Battery voltage: 3.6 V
Weight & dimensions
- Width: 228 mm
- Depth: 12.7 mm
- Height: 150 mm
- Weight: 765 g
Operational conditions
- Operating temperature (T-T): -20 - 50 °C
- Storage temperature (T-T): -20 - 60 °C
Logistics data
- Harmonized System (HS) code: 84713000
Other features
- Processor ARK ID: 96485
