Faster, better inkjet technology
Inkjet technology means that not only are printouts more detailed (600dpi compared to 180dpi for existing models), they’re around twice as fast too, with a print speed of 100mm/s (23.2lps) compared to 43mm/s (13.5lps) for previous models.
Low TCO
Epson has managed to incorporate inkjet technology into this new model while retaining a similar low total cost of ownership to previous dot matrix printers.
Simple maintenance
The ink cartridges have an easy-install design ideal for busy retail counters, as well as drop-in paper roll for quick loading, and the ink formulation used offers better water and light resistance than dot matrix, so receipts and documents will last longer.
Backwards compatible
To make upgrading from existing models incredibly easy, the TM-J7700 is fully backwards-compatible with the TM-J7500 and has exactly the same footprint, so it can simply be swapped in. However, to integrate smoothly with the latest ePOS systems, the model offers both USB and Ethernet connection options.
Printing
- Print technology: Inkjet
- Type: POS printer
- Colour: No
- Print speed: 98 mm/sec
- Print speed (graphic): 98 mm/sec
- Print speed (slip): 85 mm/sec
- Print speed (receipt): 98 mm/sec
- Printing characters: Text,Graphic,Barcode
- Character sets: ANK
- Alphanumeric memory: 95
Paper handling
- Media thickness: 0.06 - 0.09 mm
- Supported paper width: 58 - 83 mm
- Maximum paper size (slip): 230 x 297 mm
Ports & interfaces
- Connectivity technology: Wired
- USB port: Yes
- USB 2.0 ports quantity: 1
- USB connector: USB Type-B
- Ethernet LAN (RJ-45) ports: 1
Network
- Ethernet LAN: Yes
- Ethernet LAN data rates: 10,100 Mbit/s
- Wi-Fi: No
Features
- Sound pressure level (printing): 55 dB
- Mean time between failures (MTBF): 180000 h
- Half-cutter: No
- Autocutter durability: 1.5 million cuts
- Country of origin: China
- Printer slip unit life: 5000000 lines
- Printer receipt unit life: 3700000000 lines
- Safety: TÜV, TÜV (EN60950-1)
- Certification: CE, EN55024, EN55032 Class A, IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-11
Design
- Product colour: Black
Power
- AC input voltage: 24 V
- Power consumption (standby): 70000 mA
Operational conditions
- Operating relative humidity (H-H): 20 - 80 %
- Storage relative humidity (H-H): 20 - 85 %
- Operating temperature (T-T): 10 - 35 °C
- Storage temperature (T-T): -20 - 40 °C
Weight & dimensions
- Width: 251 mm
- Depth: 260 mm
- Height: 188 mm
- Weight: 5800 g
Packaging data
- Cables included: AC
- Quantity per pack: 1 pc(s)
- Package width: 350 mm
- Package depth: 390 mm
- Package height: 310 mm
- Package weight: 7880 g
Logistics data
- Pallet weight (UK): 0 g
- Harmonized System (HS) code: 84433210
- Products per pallet: 36 pc(s)
- Products per pallet layer: 6 pc(s)
- Pallet gross width: 800 mm
- Pallet gross length: 1200 mm
- Pallet gross height: 1110 mm
- Pallet gross weight: 0 g
- Products per pallet (UK): 36 pc(s)
- Products per pallet layer (UK): 6 pc(s)
- Pallet width (UK): 1000 mm
- Pallet length (UK): 1200 mm
- Pallet height (UK): 1110 mm
Technical details
- Font styles: ANK
Other features
- Mean cycles between failures (MCBF): 5000000
- Paper dimensions: 58 mm - 83 mm
