2202L
Touchscreen Monitor
The Elo 02-Series of Touchscreen Monitors designed with seamless style across all sizes includes four options — a 19-inch square aspect ratio display and 22, 24 and 27-inch wide aspect ratio displays. With a compact form factor and clean design for easy integration, the 02-Series monitors are well-suited for point-of-sale, point of information, signage and hospitality applications. And with a variety of peripherals, the monitors can be transformed to meet the demands of your blueprint.
Brilliant Displays from 19 to 27-inches
The brilliant touchscreens with Elo's industry-leading TouchPro® PCAP technology offer wide viewing angles with impeccable image clarity, resolution, and light transmission for accurate touch response and vivid images. With up to 10 touches enabled, the 02-Series Monitors, provide a tablet-like experience.
Elo Edge Connect™ Lets You do More!
Built with versatility in mind, the Elo Edge Connect system offers a wide assortment of peripheral options. Whether for endless aisle, self-order or collaboration applications, you can seamlessly attach any combination of up to four peripherals to the edge of the touchscreen creating a bespoke solution. And, you can add or move them later as your needs change!
One for You.
One for Your Customers.Offer your customers a point of interaction by adding a touchscreen for them to review their transactions, participate in loyalty programs or see the latest promotion.
One for You.
One for Your Customers.Offer your customers a point of interaction by adding a touchscreen for them to review their transactions, participate in loyalty programs or see the latest promotion.Elo touchscreen monitor in dual monitor configurationMount with FlexibilityCustomers demand a seamless shopping experience from first step into the store through check-out. From the stands that come with the monitors to pole mounts, shelf mounts, wall mounts and 3rd party VESA mounts, the touchscreens can be integrated with ease.
- Customization
Elo offers customized solutions with everything from slight modifications to ground up designs. If you need something customized.
- Global Reach
Elo products are distributed and available across the globe. Every 21 seconds, an Elo touchscreen is installed somewhere in the world.
- Long Life Cycle
We do everything in our power to minimize design changes and we've kept some monitors available to order for over seven years
Built-to-Last
The 02-Series Touchscreen Monitors deliver the quality and reliability Elo is known for and are backed by our 3-year standard warranty with an optional extension to 5-years. We design, build and are responsible for the complete solution,with touch integrated from the start.
Display
- Display diagonal: 21.5 "
- Display resolution: 1920 x 1080 pixels
- Native aspect ratio: 16
- Display technology: LCD
- Touchscreen: Yes
- HD type: Full HD
- Panel type: TFT
- Touchscreen technology: Projected capacitive system
- Touch technology: Multi-touch
- Number of simultaneous touchpoints: 10
- Display brightness (peak): 250 cd/m²
- Display brightness (typical): 225 cd/m²
- Response time: 14 ms
- Screen shape: Flat
- Supported graphics resolutions: 640 x 400,640 x 480 (VGA),720 x 400,800 x 500,800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 800 (WXGA),1366 x 768,1440 x 900 (WXGA+),1680 x 1050 (WSXGA+)
- Contrast ratio (typical): 1000
- Maximum refresh rate: 60 Hz
- Viewing angle, horizontal: 178 °
- Viewing angle, vertical: 178 °
- Display number of colours: 16.7 million colours
- Digital horizontal frequency: 30 - 82 kHz
- Digital vertical frequency: 50 - 75 Hz
Performance
- NVIDIA G-SYNC: No
- AMD FreeSync: No
Multimedia
- Built-in speaker(s): Yes
- Built-in camera: No
- Number of speakers: 2
- RMS rated power: 4 W
Design
- Market positioning: Business
- Product colour: Black
- International Protection (IP) code: IPX1
- IK code: IK06
Ports & interfaces
- Built-in USB hub: Yes
- USB hub version: 2.0
- USB upstream port type: USB Type-A,USB Type-B
- USB Touch port: Yes
- USB Touch ports quantity: 1
- VGA (D-Sub) ports quantity: 1
- HDMI: Yes
- HDMI ports quantity: 1
- Headphone out: No
- DC-in jack: Yes
Ergonomics
- VESA mounting: Yes
- Panel mounting interface: 100 x 100 mm
- Cable lock slot: No
- Height adjustment: No
- On Screen Display (OSD): Yes
- On Screen Display (OSD) languages: CHI (SIMPL),CHI (TR),DEU,ENG,ESP,FRE,ITA,JPN,KOR,RUS
Power
- Energy efficiency class (SDR): E
- Energy efficiency class (HDR): Not available
- Energy consumption (SDR) per 1000 hours: 16 kWh
- Power consumption (typical): 16.78 W
- Power consumption (standby): 0.69 W
- Power consumption (off): 0.28 W
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 20 - 80 %
- Storage relative humidity (H-H): 10 - 95 %
Packaging content
- Cables included: HDMI,VGA
Weight & dimensions
- Width (with stand): 383.8 mm
- Depth (with stand): 526.9 mm
- Height (with stand): 193.4 mm
- Weight (with stand): 6750 g
- Width (without stand): 326.9 mm
- Depth (without stand): 526.9 mm
- Height (without stand): 42.7 mm
- Weight (without stand): 4750 g
Packaging data
- Package width: 477 mm
- Package depth: 617 mm
- Package height: 260 mm
- Package weight: 10800 g
- Package type: Box
