Completely redesigned I‑Series 3 with Intel.
Brilliant and beautiful, interactive platform.
- 10-touch TouchPro PCAP
- Fanless, IP54 rated design
- Full HD IPS Touchscreen
- Easy to clean edge-to-edge glass
- 50,000 MTBF
Modular design.
Endless versatility.
Available in sizes ranging from 15 to 24 inches, including with and without stand options, you can easily configure the I‑Series to fit the needs of your business - from signage and point-of-sale to self-service, automation controls and more.
Universal VESA Mount
Conveniently mount the I‑Series with the built‑in VESA mount.
Expand with Edge Connect
Seamlessly attach a variety of peripherals to the edge of the touchscreen.
Reliable, security and performance.
Built with the reliability-tested performance and security of Intel 12th Generation processors, integrated Trusted Platform Modules, Intel vPro™ and the Windows 10 operating system, the I‑Series 3 delivers the dependability businesses need.
Enhanced connectivity for all your accessories.
- USB-C full featured
- Gigabit LAN
- Powered RJ50 Serial
- 4x USB 3.0
- 4x Micro-USB Edge Connect
- WiFi & Bluetooth 5.2
Display
- Display diagonal: 21.5 "
- Display resolution: 1920 x 1080 pixels
- Touchscreen: Yes
- HD type: Full HD
- Native aspect ratio: 16
- Display brightness: 250 cd/m²
- Panel type: LCD
Processor
- Processor manufacturer: Intel
- Processor family: Intel® Celeron®
- Processor model: 7305L
- Processor cores: 5
- Processor frequency: 1.1 GHz
- Performance cores: 1
- Efficient cores: 4
- Performance-core Max Turbo Frequency: 1.1 GHz
- Efficient-core Max Turbo Frequency: 1.1 GHz
- Processor cache: 8 MB
- Processor cache type: Smart Cache
- Maximum turbo power: 28 W
- Processor base power: 15 W
Memory
- Internal memory: 8 GB
- Internal memory type: DDR5-SDRAM
- Maximum internal memory: 32 GB
- Memory slots: 2
- Memory slots type: SO-DIMM
- Memory clock speed: 4800 MHz
- Memory layout (slots x size): 1 x 8 GB
- Memory form factor: DIMM/SO-DIMM
Storage
- Total storage capacity: 128 GB
- Storage media: SSD
- Total SSDs capacity: 128 GB
- Number of SSDs installed: 1
- SSD capacity: 128 GB
- Optical drive type: No
Graphics
- Discrete graphics card: No
- Discrete graphics card model: Not available
- On-board graphics card: Yes
- On-board GPU manufacturer: Intel
- On-board graphics card family: Intel® UHD Graphics
- On-board graphics card model: Intel® UHD Graphics
Audio
- Built-in speaker(s): Yes
- Number of speakers: 2
- RMS rated power: 4 W
Camera
- Built-in camera: No
Network
- Wi-Fi: Yes
- Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
- Wi-Fi standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
- Ethernet LAN: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- Bluetooth: Yes
- Bluetooth version: 5.2
Ports & interfaces
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 0
- HDMI ports quantity: 0
- Headphone outputs: 1
- DC-in jack: Yes
Design
- Product colour: Black
- On/off button: Yes
Performance
- Product type: All-in-One PC
- Trusted Platform Module (TPM): Yes
- Trusted Platform Module (TPM) version: 2.0
- HDD user password: Yes
Software
- Operating system installed: No
Power
- AC adapter power: 180 W
- AC adapter frequency: 50 - 60 Hz
- AC adapter input voltage: 100 - 240 V
- AC adapter output voltage: 24 V
Weight & dimensions
- Width (with stand): 525.8 mm
- Depth (with stand): 204.6 mm
- Height (with stand): 368.7 mm
- Weight (with stand): 10100 g
- Package width: 645 mm
- Package depth: 316 mm
- Package height: 503 mm
- Package weight: 12000 g
Operational conditions
- Operating temperature (T-T): 0 - 35 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 20 - 80 %
- Storage relative humidity (H-H): 5 - 95 %
Certificates
- Compliance certificates: RoHS
- Certification: Canada cUL, IC; United States UL, FCC; Germany TUV; Europe CE; Australia RCM; United Kingdom UKCA; International CB; Argentina S-Mark; Brazil; ANATEL; Japan VCCI, MIC; China CCC, SRRC; Mexico NOM; RoHS CoC
Sustainability
- Sustainability compliance: Yes
