Modular design.
Endless versatility.
Available in sizes ranging from 15 to 24 inches, including with
and without stand options, you can easily configure the I‑Series
to fit the needs of your business - from signage and point-of-sale
to self-service, automation controls and more.
Reliable, security and performance.
Built with the reliability-tested performance and security of Intel 12th
Generation processors, integrated Trusted Platform Modules, Intel
vPro™ and the Windows 10 operating system, the I‑Series 3 delivers
the dependability businesses need.
Display
- Display diagonal: 17 "
- Display resolution: 1280 x 1024 pixels
- Touchscreen: Yes
- Native aspect ratio: 5
- Display brightness: 250 cd/m²
- Response time: 25 ms
- Panel type: TFT
- Viewing angle, horizontal: 170 °
- Contrast ratio (typical): 1000
- Screen shape: Flat
- Viewing angle, vertical: 160 °
Processor
- Processor manufacturer: Intel
- Processor family: Intel® Core™ i7
- Processor generation: 12th gen Intel® Core™ i7
- Processor model: i7-1265UL
- Processor threads: 12
- Processor frequency: 1.8 GHz
- Efficient cores: 8
- Performance-core Max Turbo Frequency: 4.8 GHz
- Efficient-core Max Turbo Frequency: 2.7 GHz
- Processor cache: 12 MB
- Processor cache type: Smart Cache
- Processor base power: 15 W
Memory
- Internal memory: 16 GB
- Internal memory type: DDR5-SDRAM
- Maximum internal memory: 32 GB
- Memory slots type: SO-DIMM
- Memory clock speed: 4800 MHz
Storage
- Total storage capacity: 128 GB
- Storage media: SSD
- Total SSDs capacity: 128 GB
- Number of SSDs installed: 1
- SSD capacity: 128 GB
- SSD interface: PCI Express 4.0
- NVMe: Yes
- SSD form factor: M.2
Graphics
- On-board graphics card: Yes
- On-board graphics card family: Intel Iris Xe Graphics
- On-board graphics card model: Intel Iris Xe Graphics
Audio
- Built-in speaker(s): Yes
- Number of speakers: 2
- RMS rated power: 4 W
Network
- Wi-Fi: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Wi-Fi standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
- Ethernet LAN: Yes
- Bluetooth: Yes
- Bluetooth version: 5.0
Ports & interfaces
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- Headphone outputs: 1
Design
- Product colour: Black
- Panel mounting interface: 100 x 100 mm
- VESA mounting: Yes
Performance
- Product type: All-in-One tablet PC
- Trusted Platform Module (TPM): Yes
- Trusted Platform Module (TPM) version: 2.0
Software
- Operating system installed: Windows 10
- Operating system architecture: 64-bit
Power
- AC adapter frequency: 50 - 60 Hz
- AC adapter input voltage: 100 - 240 V
- Power consumption (typical): 54 W
Weight & dimensions
- Width (with stand): 393.4 mm
- Depth (with stand): 205.6 mm
- Height (with stand): 371.2 mm
- Package width: 529 mm
- Package depth: 315 mm
- Package height: 539 mm
Operational conditions
- Operating temperature (T-T): 0 - 35 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 20 - 80 %
- Storage relative humidity (H-H): 5 - 95 %
Other features
- Mean time between failures (MTBF): 50000 h
