Boost efficiency and deliver exceptional customer service at every touchpoint with the DS8208 corded scanner. Featuring an advanced 2 MP optical system that sets a new benchmark for scan performance and a multi-function button to streamline workflows, the DS8208 provides the speed and reliability your team needs to keep transactions moving.
Scanning
- Type: Handheld bar code reader
- Scanner type: 1D/2D
- Sensor type: LED
- Linear (1D) barcodes supported: AIM-128,Codabar,Code 11,Code 128,Code 39,Code 93,GS1 Composite,GS1 DataBar,GS1 DataBar Expanded,GS1 DataBar Omnidirectional,GS1 Databar Limited,GS1 Databar RSS14,GS1-128 (UCC/EAN-128),IATA,Industrial 2 of 5,Interleaved 2 of 5,ISBN,ISBT 128,ISSN,ITF-14,ITF
- 2D (matrix & stacked) barcodes supported: Aztec Code,Han Xin,MaxiCode,Micro QR Code,MicroPDF417,PDF417,QR Code,SecurPharm,TLC-39
- Optical sensor resolution (W x H): 1600 x 1200 pixels
- Horizontal field of view: 48 °
- Vertical field of view: 36 °
- Light levels (direct sunlight): 0 - 107.6 lx
- Pitch reading angle: 0 - 60 °
Ports & interfaces
- Connectivity technology: Wired & Wireless
- Standard interfaces: RS-232,USB
- Bluetooth Low Energy (BLE): Yes
- Bluetooth version: 5.2
Performance
- Product colour: Black
- International Protection (IP) code: IP52
- Ambient lighting: Yes
- Print contrast: 16 %
Power
- Power source type: DC
- Battery technology: Lithium-Ion (Li-Ion)
- Battery type: Built-in battery
- Charging port type: USB Type-C
- Battery capacity: 3500 mAh
- Battery life: 108 h
- Charging time: 6.7 h
Weight & dimensions
- Weight: 176.5 g
Operational conditions
- Drop resistance: 3 m
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 0 - 95 %
