IMPROVE PATIENT SAFETY AND CLINICIAN PRODUCTIVITY
Purpose-built for healthcare, you get an affordable imager that doesn’t compromise performance or features for price. Capture the many kinds of barcodes commonly used in hospitals—from barcodes on patient wristbands and medication vials to IV bags and specimen trays. Pre-configured and ready to use right out of the box, the scanner is configured for the healthcare applications you use every day, while auto-host detect cables automatically select the right host interface—just plug in the scanner and you’re ready to go.
Scanning
- Type: Handheld bar code reader
- Scanner type: 1D/2D
- Linear (1D) barcodes supported: Codabar,Code 11,Code 128,Code 39,Code 93,EAN 128,EAN 2,EAN 5,EAN-13,EAN-8,MSI,U.P.C.,UPC-A,UPC-E
- Sensor type: LED
- Optical sensor resolution (W x H): 640 x 480 pixels
- Light levels (direct sunlight): 0 - 107600 lx
- Wavelength: 624 nm
- Tilt reading angle: 0 - 360 °
- Pitch reading angle: 0 - 65 °
- Yaw reading angle: 0 - 65 °
Ports & interfaces
- Connectivity technology: Wired
- Standard interfaces: Keyboard wedge,RS-232,USB
Performance
- Product colour: White
- International Protection (IP) code: IP52
- LED indicators: Yes
- Buzzer: Yes
- Certification: RoHS EN 50581, EN 60950-1 2ed + A11 + A1 + A12 + A2
Power
- Power source type: RS-232,USB
- Input voltage: 4.5 - 5.5 V
Weight & dimensions
- Width: 66 mm
- Depth: 99 mm
- Height: 165 mm
- Weight: 161.6 g
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
- Operating relative humidity (H-H): 5 - 95 %
- Storage temperature (T-T): -40 - 70 °C
Logistics data
- Harmonized System (HS) code: 84716070
