- High-speed printing at up to 300 mm/sec possible
- Stylish design
- Compact size with the lowest possible height
- The front paper eject structure enables use where the height is restricted
- Compliant with IPX1 for drip-proof capabilities
- Support for paper widths of 80 mm and 58 mm
- High-speed cutter employed
- Long Life Printing (LLP) function to increase the head life available
- USB interface included as standard
- Interchangeable interface board
- Printer status and errors indicated by five LEDs
- Built-in drawer kick interface
- USB-linked power OFF function available
- 16 level greyscale and clear printing
- Paper saving function available
- Support for the JIS X0213 third and fourth level Kanji character sets
- Support for the simplified and traditional Chinese character sets and Hangul character set
- Support for UTF-8 using commands
- Various customizations using the memory switches possible
- User created characters and logos can be saved in the user memory
- Support for barcodes including 2D barcodes
Printing
- Print technology: Thermal
- Type: POS printer
- Maximum resolution: 203 x 203 DPI
- Print speed: 300 mm/sec
- Character size: 1.5 x 3 mm
- Character sets: Katakana,PC437,PC850,PC858,PC860,PC863,Thai code 18,WPC1252
Paper handling
- Maximum roll diameter: 83 mm
- Maximum printing width: 72 mm
- Printing media thickness: 53 - 85 µm
Ports & interfaces
- Connectivity technology: Wired
- USB port: Yes
- USB 2.0 ports quantity: 1
Network
- Ethernet LAN: No
- Wi-Fi: No
Features
- Built-in barcodes: CODABAR (NW-7),Code 128 (A/B/C),Code 39,Code 93,EAN13,EAN8,GS1 DataBar,ITF,PDF417,QR Code,UPC-A,UPC-E
- Internal memory: 0.375 MB
- Certification: UL, C-UL, FCC Cl. A, CE
Design
- Product colour: White
Power
- Power source type: DC
- Power consumption (printing): 50 W
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Input current: 2.1 A
Operational conditions
- Operating temperature (T-T): 5 - 45 °C
- Storage relative humidity (H-H): 10 - 90 %
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 10 - 90 %
Weight & dimensions
- Width: 125 mm
- Depth: 165 mm
- Height: 108 mm
- Weight: 1300 g
Packaging data
- Cables included: AC
Packaging content
- AC adapter included: Yes
- Quick start guide: Yes
Logistics data
- Harmonized System (HS) code: 84433210
Technical details
- Voltage: 24 V
Other features
- LED indicators: Power
- Buffer size: 4 KB
