ULTRA-VERSATILE WITH A FIRST-OF-ITS-KIND CONVERTIBLE DESIGN
The ultra-versatile CS60 Series Companion Scanner adapts to any workflow. Its groundbreaking design easily converts between corded and cordless operation, handheld and hands-free, as your needs change for superior investment protection.
ADAPTS TO ANY WORKFLOW
As a cordless companion scanner, the CS60 is small enough to tuck in a pocket or wear on a lanyard. And as a corded scanner, the CS60 offers compact handheld or hands-free scanning for the checkout counter, self-service kiosk and more. Whether you purchase a corded or cordless model up front, you can change modes at any time.
CUTTING-EDGE MOBILITY
With Qi inductive charging, split-second NFC tap-to-pair, Bluetooth 5.0 with Wi-Fi friendly mode, an 18-hour battery and Virtual Tether anti-loss functionality, the cordless CS60 is pocketable and wearable when mobility is essential.
EASY TO CONFIGURE AND MANAGE
DataCapture DNA is a unique collection of value-add tools that make it easier to deploy, update, troubleshoot, manage and develop applications for your business.
Scanning
- Type: Handheld bar code reader
- Scanner type: 1D/2D
- 2D (matrix & stacked) barcodes supported: Aztec Code,Composite Codes,Data Matrix,Han Xin,MaxiCode,Micro QR Code,MicroPDF417,PDF417,QR Code,TLC-39
- Sensor type: LED
- Linear (1D) barcodes supported: Codabar,Code 11,Code 128,Code 39,Code 93,GS1 DataBar,MSI,Plessey,U.P.C.
- Optical sensor resolution (W x H): 1280 x 960 pixels
- Light levels (direct sunlight): 0 - 108000 lx
- Wavelength: 525 nm
- Tilt reading angle: -60 - 60 °
- Pitch reading angle: -60 - 60 °
- Yaw reading angle: 0 - 360 °
Ports & interfaces
- Connectivity technology: Wireless
- Standard interfaces: Bluetooth,USB
- Wireless range: 100 m
- Bluetooth Low Energy (BLE): Yes
- Bluetooth version: 5.0
Performance
- Product colour: Black
- International Protection (IP) code: IP65
- LED indicators: Yes
Power
- Power source type: AC,Battery,DC,USB
- Battery technology: Lithium Polymer (LiPo)
- Battery type: Built-in battery
- Battery capacity: 735 mAh
- Number of reads per charge: 13000
- Battery life: 18 h
- Charging time: 6 h
- Power consumption: 400 mA
Weight & dimensions
- Width: 46 mm
- Depth: 109 mm
- Height: 23 mm
- Base weight: 138 g
- Weight: 83 g
- Base dimensions (WxDxH): 113 x 78 x 107 mm
Packaging data
- Charging base: Yes
Operational conditions
- Operating relative humidity (H-H): 5 - 95 %
- Storage relative humidity (H-H): 5 - 95 %
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -40 - 70 °C
Technical details
- Compliance certificates: RoHS
Logistics data
- Harmonized System (HS) code: 84716070
