ULTRA-VERSATILE WITH A FIRST-OF-ITS-KIND CONVERTIBLE DESIGN
The ultra-versatile CS60-HC Healthcare Series Companion Scanner is designed specifically for healthcare and adapts to any clinician workflow. Its groundbreaking design easily converts between corded and cordless operation, handheld and hands-free, as your needs change for superior investment protection. And it features a purpose-built housing that helps offer maximum protection against the spread of bacteria, including a crevice-free surface that helps eliminate places where germs can hide.
ADAPTS TO ANY CLINICIAN WORKFLOW
As a cordless companion scanner, the CS60-HC is small enough to meet any nurse-carry workflow. And as a corded scanner, the CS60-HC provides compact scanning for the pharmacy counter, lab station and more. Whether you purchase a corded or cordless model up front, you can change modes at any time.
CUTTING-EDGE CLINICAL MOBILITY
With Qi inductive charging, split-second NFC tap-to-pair, Bluetooth 5.0 with Wi-Fi friendly mode, an 18-hour battery and Virtual Tether anti-loss functionality, the cordless CS60-HC is pocketable and wearable when clinician mobility is essential.
PURPOSE BUILT FOR HEALTHCARE
Thanks to a safe LED aimer, night mode and an IP65 sealed disinfectant-ready housing with a crevice-free surface that helps eliminate places where germs can hide, the CS60-HC is designed to be used throughout the whole hospital including the NICU, labour and delivery and mother-baby units.
Scanning
- Type: Handheld bar code reader
- Scanner type: 1D/2D
- 2D (matrix & stacked) barcodes supported: Aztec Code,Composite Codes,Data Matrix,Han Xin,MaxiCode,Micro QR Code,MicroPDF417,PDF417,QR Code,TLC-39
- Sensor type: LED
- Linear (1D) barcodes supported: Codabar,Code 11,Code 128,Code 39,Code 93,GS1 DataBar,MSI,Plessey,U.P.C.
- Optical sensor resolution (W x H): 1280 x 960 pixels
- Light levels (direct sunlight): 0 - 108000 lx
- Wavelength: 525 nm
- Tilt reading angle: -60 - 60 °
- Pitch reading angle: -60 - 60 °
- Yaw reading angle: 0 - 360 °
Ports & interfaces
- Connectivity technology: Wireless
- Standard interfaces: Bluetooth,USB
- Wireless range: 100 m
- Bluetooth Low Energy (BLE): Yes
- Bluetooth version: 5.0
Performance
- Product colour: White
- International Protection (IP) code: IP65
- LED indicators: Yes
- Certification: FIPS 140-2
Power
- Power source type: AC,Battery,DC,USB
- Battery technology: Lithium Polymer (LiPo)
- Battery type: Built-in battery
- Battery capacity: 735 mAh
- Number of reads per charge: 13000
- Battery life: 18 h
- Charging time: 6 h
- Power consumption: 400 mA
Weight & dimensions
- Width: 46 mm
- Depth: 109 mm
- Height: 23 mm
- Weight: 87 g
Operational conditions
- Storage relative humidity (H-H): 5 - 95 %
- Operating relative humidity (H-H): 5 - 95 %
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -40 - 70 °C
Technical details
- Compliance certificates: RoHS
