Improved Performance
- Flexible character alignment on display (Horizontal, vertical, font space and line space)
- Adjust alignment (Center, left and right)
- Maximum 120 characters display
- Two character font available (8 x 16, 9 x 17)
- 250% enhanced reliability as compared BCD-1000/1100
- Simple download and display image by utility
Highly Flexible Design
- Adjustable display height
- Optional wall mount
- 13° five option angle adjustor and 360° screen rotation
- Easy connection to the host via USB cable pass-through design
Hardware Compatibility
- Easy plug and play USB set up
- Compatible with all major operating systems including Android™, iOS™ and Windows®
Display
- Display digits: 120 digits
- Digit pitch: 0.03 mm
- Display brightness: 100 cd/m²
- Display size (HxV): 127.2 x 33.9 mm
- Illumination colour: Blue,White
Features
- Product colour: Black
- Tilt angle range: 0 - 13 °
- Height adjustment range: 167 - 521 mm
Ports & interfaces
- Interface: USB 2.0
- Optional connectivity: Serial (RS-232),USB 2.0
Operational conditions
- Storage relative humidity (H-H): 10 - 90 %
- Operating relative humidity (H-H): 10 - 80 %
- Storage temperature (T-T): -20 - 55 °C
- Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
- Depth: 97.6 mm
- Width: 162.5 mm
- Weight: 850 g
- Height: 521 mm
