The TD-4550DNWBFC is a user-friendly desktop linerless label printer with an intuitive LCD screen. Its professional-quality resolution makes it ideal for printing 2D barcodes, ensuring easy scanning and quick processing.
Bluetooth connectivity allows for setup and configuration via a smartphone or tablet using the Mobile Deploy App, while wireless connectivity eliminates the need for network cables.
Printing
- Print technology: Direct thermal
- Colour: No
- Maximum resolution: 300 x 300 DPI
- Print speed: 152 mm/sec
- Maximum printing width: 108 mm
- Maximum print height: 3000 mm
- Minimum print length: 6.4 mm
Paper handling
- Maximum print size: 108 x 3000 mm
- Autocutter: Yes
- Maximum label width: 118 mm
- Maximum roll diameter: 127 mm
Ports & interfaces
- Connectivity technology: Wired & Wireless
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Wi-Fi standards: 802.11b,802.11g,Wi-Fi 4 (802.11n)
- Bluetooth: Yes
- Bluetooth Low Energy (BLE): Yes
- Bluetooth version: 4.2
- Bluetooth profiles: GATT,HCRP,OPP,SPP
- USB port: Yes
- USB 2.0 ports quantity: 1
- RS-232 ports: 1
- Mobile printing technologies: Apple AirPrint
Performance
- Page description languages: ESC P
- Internal memory: 256 MB
- Flash memory: 64 MB
- Built-in barcodes: AZTECCODE,CODABAR (NW-7),Code 128 (A/B/C),Code 39,Code 93,Data Matrix,EAN13,EAN8,GS1 DataBar,GS1 DataBar Expanded,GS1 DataBar Limited,GS1 DataBar Omnidirectional,GS1 DataBar Truncated,GS1-128,ITF,MSI,MaxiCode,PDF417,POSTNET,QR Code,UPC-A,UPC-E
Design
- Product colour: Black,White
- Built-in display: Yes
- Display: LCD
- Control type: Buttons
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- Power source type: USB
System requirements
- Mobile operating systems supported: Android 10,Android 10.0,Android 11.0,Android 12.0,Android 13.0,Android 5.0,Android 5.1,Android 6.0,Android 7.0,Android 7.1,iOS 10.0,iOS 11.0,iOS 11.4,iOS 12,iOS 13,iOS 13.4,iOS 14,iOS 14.5,iOS 15,iOS 16,iOS 9.0,iOS 9.1,iOS 9.2,iOS 9.3
- Server operating systems supported: Windows Server 2016,Windows Server 2019,Windows Server 2022
- Linux operating systems supported: Yes
- Windows operating systems supported: Windows 10,Windows 11
Operational conditions
- Operating relative humidity (H-H): 20 - 85 %
- Storage relative humidity (H-H): 10 - 90 %
- Storage temperature (T-T): -20 - 60 °C
- Operating temperature (T-T): 5 - 40 °C
Weight & dimensions
- Width: 266 mm
- Depth: 261 mm
- Height: 336 mm
- Weight: 3426 g
Packaging data
- Package width: 266 mm
- Package depth: 261 mm
- Package height: 336 mm
- Package weight: 4350 g
- Package type: Box
Packaging content
- Cables included: AC,USB
- Quick start guide: Yes
- AC adapter included: Yes
Logistics data
- Pallet gross height: 142.5 mm
- Pallet gross weight: 194000 g
- Master (outer) cases per pallet: 40 pc(s)
- Master (outer) cases per pallet layer: 8 pc(s)
- Layers per pallet: 5 pc(s)
- Products per pallet: 40 pc(s)
Technical details
- Warranty period: 3 year(s)
- Pallet type: 800 x 1200 mm
Other features
- Country of origin: China
