Experience the best of both worlds with the TD-2350DSA203: standalone functionality with advanced connectivity. Store up to 255 label designs and select to print with the keyboard and tiltable color touch LCD display for offline printing. Utilize the real-time clock to program auto-time stamp for food expiration or maintenance due. Build out further efficiency with an optional cutter or label peeler to adapt your printing operations to business needs. And with Wi-Fi® and Bluetooth® wireless connectivity, you get flexible point-of-application printing that boosts efficiency and service.
Printing
- Print technology: Direct thermal
- Colour: No
- Maximum resolution: 203 x 203 DPI
- Print speed: 152 mm/sec
- Maximum printing width: 59 mm
- Minimum print length: 6.4 mm
Paper handling
- Ribbon length: 3 m
- Maximum roll diameter: 127 mm
- Media thickness: 0.058 - 0.279 mm
- Maximum label length: 3 m
Ports & interfaces
- Connectivity technology: Wired & Wireless
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Wi-Fi standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n)
- Bluetooth: Yes
- Bluetooth version: 5.2+EDR
- USB port: Yes
- USB 2.0 ports quantity: 1
- RS-232 ports: 1
Performance
- Page description languages: ESC P,Raster_P
- Internal memory: 256 MB
- Built-in barcodes: AZTECCODE,CODABAR (NW-7),Code 128 (A/B/C),Code 39,Code 93,Data Matrix,EAN13,EAN8,GS1 DataBar,MSI,MaxiCode,Micro QR Code,POSTNET,QR Code,UPC-A,UPC-E
- Number of fonts: 10
- Security algorithms: 64-bit WEP,128-bit WEP,EAP-FAST,EAP-TLS,EAP-TTLS,PEAP,WPA-PSK,WPA2-PSK,WPA3-SAE
Design
- Product colour: Black,Grey
- Built-in display: Yes
- Display: LCD
- Colour display: Yes
- Control type: Buttons,Touch
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- AC adapter output voltage: 24 V
- AC adapter output current: 3.6 A
- USB port voltage: 5 V
- USB port current: 3 A
- Power source type: AC
System requirements
- Windows operating systems supported: Windows 10,Windows 11
- Mobile operating systems supported: Android,iOS
- Linux operating systems supported: Yes
Operational conditions
- Operating relative humidity (H-H): 20 - 80 %
- Storage relative humidity (H-H): 10 - 90 %
- Operating temperature (T-T): 5 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
- Width: 181 mm
- Depth: 306 mm
- Height: 325 mm
- Weight: 1864 g
Packaging data
- Package width: 306 mm
- Package depth: 181 mm
- Package height: 325 mm
- Package weight: 2901 g
Packaging content
- Cables included: USB
Logistics data
- Pallet gross height: 177.5 mm
- Pallet gross weight: 631200 g
- Master (outer) cases per pallet: 20 pc(s)
- Master (outer) cases per pallet layer: 4 pc(s)
- Layers per pallet: 5 pc(s)
- Products per pallet: 60 pc(s)
Technical details
- Warranty period: 3 year(s)
- Pallet type: 800 x 1200 mm
Other features
- Country of origin: Vietnam
- Spare part retention: 5 year(s)
