Looking for the perfect scanning companion for your tablet-based retail point-of-sale and field service applications? The affordable Voyager™ 1602g wireless scanner is the one. It packs high-performance area-imaging technology into an elegant and pocketable form factor that makes scanning easy and – dare we say – fun.
Full-Size Performance
Features the same performance area-imaging engine found in our full-size scanners, so you can scan virtually all 1D and 2D barcodes with ease.
A Mobile Marketing Enabler
Lets you scan barcodes off smartphone screens – mobile coupons, e-tickets, digital wallets, and digital loyalty cards.
Ergonomically Designed
Contoured and elegant design, over-sized scan button, and light weight make scanning fun.
Efficient Wireless Performance
Bluetooth® wireless technology provides freedom of movement up to 10 m (33 ft) from host device.
User-Replaceable Battery
Rated for more than 2,250 scans on a single charge; rechargeable over standard microUSB.
Scanning
- Type: Handheld bar code reader
- Scanner type: 1D/2D
- 2D (matrix & stacked) barcodes supported: Aztec Code,Codablock,Data Matrix,MaxiCode,MicroPDF417,PDF417,QR Code
- Light levels (direct sunlight): 0 - 100000 lx
- Pitch reading angle: -60 - 60 °
- Motion tolerance (cm/s): 10
- Optical sensor resolution: 640 pixels
Ports & interfaces
- Connectivity technology: Wireless
- Standard interfaces: Bluetooth,USB
- USB version: 2.0
- USB 2.0 ports quantity: 1
- Data transfer rate: 1 Mbit/s
- Wireless range: 10 m
- Bluetooth version: 2.1+EDR
- Operating frequency: 2400 - 2500 MHz
- PC connection: USB 2.0
Performance
- Product colour: Black
- Housing material: Plastic
- International Protection (IP) code: IP42
- Keys quantity: 2 keys
- LED indicators: Yes
- Programming function: Yes
Power
- Power source type: Battery
- Battery technology: Lithium-Ion (Li-Ion)
- Number of batteries supported: 1
- Battery capacity: 750 mAh
- Battery voltage: 3.7 V
- Number of reads per charge: 2250
- Battery life: 12 h
- Charging time: 3 h
Weight & dimensions
- Width: 48 mm
- Depth: 22 mm
- Height: 120 mm
- Weight: 100 g
Operational conditions
- Storage temperature (T-T): -20 - 60 °C
- Operating temperature (T-T): 0 - 50 °C
- Operating relative humidity (H-H): 0 - 95 %
Logistics data
- Harmonized System (HS) code: 84716070
Other features
- Windows operating systems supported: Yes
- Mobile operating systems supported: Android,Windows Mobile,iOS
