The Elo Touch Solutions 1523L 15-inch touchmonitor is well-suited to meet the durability and aesthetic requirements for a variety of high traffic retail and hospitality interactive solutions. Retail peripheral accessories include an encryptable MSR, NFC/RFID for contactless payments, webcam, and rear-facing display bracket.
The edge to edge flat glass style of the 1523L brings a sleek, modern feel to any application. It is available in two touchscreen technologies, IntelliTouch Zero-Bezel surface acoustic wave, and IntelliTouch Pro projected capacitive with anti-glare surface coating, supporting 10-touch interaction right out of the box.
Both touch technologies provide a stable "drift-free" operation with outstanding image clarity, resolution and light transmission - for an accurate touch response and vivid images.
Display
- Display diagonal: 15 "
- Display resolution: 1024 x 768 pixels
- Display brightness: 270 cd/m²
- Touchscreen: Yes
- Contrast ratio (typical): 700
- Viewing angle, horizontal: 160 °
- Viewing angle, vertical: 140 °
- Response time: 16 ms
- LED backlight: Yes
- Native aspect ratio: 4
Features
- Product colour: Black
- Mean time between failures (MTBF): 50000 h
Packaging data
- Package depth: 207 mm
- Package height: 380 mm
- Package weight: 7000 g
- Package width: 447 mm
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 20 - 80 %
- Storage relative humidity (H-H): 10 - 95 %
