Display
- Display diagonal: 15.6 "
- Display resolution: 1920 x 1080 pixels
- Native aspect ratio: 16
- Display technology: LED
- Touchscreen: Yes
- HD type: Full HD
- Panel type: TFT
- Touchscreen type: Multi-user
- Touchscreen technology: Projected capacitive system
- Touch technology: Multi-touch
- Number of simultaneous touchpoints: 10
- Display brightness: 250 cd/m²
- Response time: 30 ms
- Anti-glare screen: Yes
- Screen shape: Flat
- Supported graphics resolutions: 640 x 480 (VGA),720 x 400,800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 800,1280 x 960,1360 x 768 (WXGA),1366 x 768,1440 x 900,1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080)
- Contrast ratio (typical): 700
- Maximum refresh rate: 60 Hz
- Viewing angle, horizontal: 160 °
- Viewing angle, vertical: 160 °
- Display number of colours: 16.7 million colours
- Viewable size, horizontal: 344.16 mm
- Viewable size, vertical: 193.5 mm
- Digital horizontal frequency: 31.5 - 82 kHz
- Digital vertical frequency: 50 - 75 Hz
Performance
- NVIDIA G-SYNC: No
- AMD FreeSync: No
Multimedia
- Built-in speaker(s): Yes
- Built-in camera: No
- Number of speakers: 2
- RMS rated power: 4 W
- Built-in microphone: No
Design
- Market positioning: Medical
- Product colour: Black
- International Protection (IP) code: IP22
Ports & interfaces
- USB Touch port: Yes
- VGA (D-Sub) ports quantity: 1
- HDMI: Yes
- HDMI ports quantity: 1
- PC Audio in: Yes
- DC-in jack: Yes
Ergonomics
- VESA mounting: Yes
- Panel mounting interface: 75 x 75,100 x 100 mm
- Wall mountable: Yes
- On Screen Display (OSD): Yes
- On Screen Display (OSD) languages: CHI (SIMPL),DEU,ENG,ESP,FRE,ITA,JPN
Power
- Energy efficiency class (SDR): E
- Energy consumption (SDR) per 1000 hours: 10 kWh
- Power consumption (typical): 9.5 W
- Power consumption (standby): 1.27 W
- Power consumption (off): 0.2 W
- Energy efficiency scale: A to G
- European Product Registry for Energy Labelling (EPREL) code: 1504232
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 20 - 80 %
- Storage relative humidity (H-H): 10 - 95 %
Packaging content
- Cables included: AC,HDMI,USB
Weight & dimensions
- Width (without stand): 244.39 mm
- Depth (without stand): 32.4 mm
- Height (without stand): 386.96 mm
- Weight (without stand): 1640 g
Packaging data
- Package width: 204 mm
- Package depth: 344 mm
- Package height: 451 mm
- Package weight: 5100 g
