Elo’s 1502L
Touchscreen Monitor
The Elo 1502L Touchscreen Monitor is designed with the same seamless style that spans across the entire line up of 02-Series Monitors. With a compact form factor and clean design for easy integration, the 1502L offers the flexibility to install as a traditional POS terminal or a customer facing point of interaction - making it well-suited for point-of-sale, self-service, signage and hospitality applications. And with a variety of peripherals, the monitor can be transformed to meet the demands of almost any blueprint.
Single Cable Connection
The 1502L provides a USB Type-C interface that provides touch, video and power. By reducing the number of cables required for any set up from 3 to 1, installation and servicing is a breeze. In case your PC isn’t equipped with USB Type-C yet, you can still use traditional HDMI or VGA to connect to your PC.
One for You.
One for Your Customers.
The 02-Series offers dual functionality. Use it as a traditional POS terminal or customer facing display – or BOTH! Start increasing brand loyalty and customer satisfaction by offering your customers a point of interaction to review transactions, participate in loyalty programs or see the latest promotion.
Well-Suited for…
Not all businesses have the same needs. Whether you need a touchscreen at the point of sale to process a transaction or in a restaurant to enable self-service for guests to view your menu and submit their order, the line of 02-Series monitors can support the installation needs with ease while maintaining a modern, sleek aesthetic.
Elo Edge Connect™ Lets You do More!
Built with versatility in mind, the Elo Edge Connect system offers a wide assortment of peripheral options. Whether for endless aisle, self-order or collaboration applications, you can seamlessly attach any combination of up to four peripherals to the edge of the touchscreen creating a bespoke solution. And, you can add or move them later as your needs change!
Mount with Flexibility
Customers demand a seamless shopping experience from their first step into the store through check-out. From the stands that come with the monitors to pole mounts, shelf mounts, wall mounts and 3rd party kiosk enclosures, the touchscreens can be integrated with ease.
Display
- Display diagonal: 15.6 "
- Display technology: LED
- Panel type: TFT
- Display resolution: 1920 x 1080 pixels
- HD type: Full HD
- Touchscreen: Yes
- Native aspect ratio: 16
- Response time: 30 ms
- Contrast ratio (typical): 700
- Viewing angle, horizontal: 160 °
- Viewing angle, vertical: 160 °
- Display number of colours: 262144 colours
- Horizontal scan range: 31.5 - 82 kHz
- Vertical scan range: 50 - 75 Hz
- Supported graphics resolutions: 640 x 400,640 x 480 (VGA),720 x 400,800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 800 (WXGA),1280 x 960,1360 x 768 (WXGA),1366 x 768,1440 x 900 (WXGA+),1680 x 1050 (WSXGA+)
Ports & interfaces
- HDMI ports quantity: 1
- DC-in jack: Yes
Audio
- Built-in speaker(s): Yes
- RMS rated power: 2 W
Design
- Product colour: Black
- Screen shape: Flat
- VESA mounting: Yes
- Panel mounting interface: 75 x 100 mm
- Anti-glare screen: Yes
Performance
- On Screen Display (OSD): Yes
- International Protection (IP) code: IPX1
Power
- Power consumption (typical): 9.5 W
- Power consumption (standby): 1.87 W
- Power consumption (off): 0.2 W
- Energy efficiency class (SDR): E
- Energy consumption (SDR) per 1000 hours: 12 kWh
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Energy efficiency scale: A to G
Weight & dimensions
- Width (with stand): 284.65 mm
- Depth (with stand): 199.12 mm
- Height (with stand): 386.96 mm
- Weight (with stand): 3050 g
Packaging data
- Package width: 204 mm
- Package depth: 451 mm
- Package height: 344 mm
- Package weight: 5010 g
Packaging content
- Cables included: AC,HDMI,USB Type-A to USB Type-C
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 20 - 80 %
- Storage temperature (T-T): -20 - 60 °C
- Storage relative humidity (H-H): 10 - 95 %
Logistics data
- Harmonized System (HS) code: 85285210
Other features
- Viewable size, vertical: 193.5 mm
- Viewable size, horizontal: 344.16 mm
- Quick start guide: Yes
- Package type: Box
